| Place of Origin: | China |
| Brand Name: | Global Tech |
| Certification: | ISO9001 |
| Model Number: | DIU-8ETH |
| Minimum Order Quantity: | 1 Unit |
|---|---|
| Price: | To be negotiated. |
| Packaging Details: | Export Carton |
| Delivery Time: | 7 days after payment clear |
| Payment Terms: | LC/TT/WU |
| Serial Port: | RS232, RS485, RS422, Three In One | Serial Type: | Aviation Socket |
|---|---|---|---|
| RJ45 Interface: | Aviation Socket | Power Interface: | Aviation Socket |
| Water Proof: | IP68 | Material: | CNC Aluminum Magnesium Alloy |
DIU-8ETH is a serial server specially designed for the military, which can meet the requirements of high temperature, explosion-proof, waterproof and shock resistance in complex and harsh battlefield environments. It can be used for weapon control, radar data transmission, satellite positioning data transmission, gyroscope, compass and other data conversion and transmission. DIU-8ETH adopts all-aluminum-magnesium alloy CNC production skill, military green, and IP68 protection level.
Parameters:
| CPU: | 32-bit 100M |
| Memory: | 16M Bytes |
| OS: | uClinux |
| Power(Aviation socket): | 220V AC or 12V~48V DC |
| Shell: | CNC aluminum magnesium alloy, 1U |
| Dust and Waterproof: | Sealed, IP68 |
| Working temperature: | -40 ℃~80 ℃ |
| Working humidity: | 0 ~ 95% non-condensing |
| Storage temperature: | -40~80 ℃ |
| Storage humidity: | 0 ~ 95% non-condensing |
| RJ45 interface(Aviation socket): | 10M/100M adaptive Ethernet, automatic identification of straight-through/crossover cable |
| Ethernet Protocol: | TCP, UDP, IP, ARP, HTTP, DHCP, ICMP, Telnet |
| Number of serial ports: | 8 |
| Serial interface type: | Aviation socket |
| Interface speed: | RS232 > 1M, RS422/RS485 > 10M |
| RS2322 signal: | TXD, RXD, CTS, RTS, DCD, DTR, DSR, RI |
| RS485(FULL) signal: | A,B,Y,Z |
| RS485(half) signal: | A,B |
| Serial port protection: | 15KV ESD, 2KV lightning protection |
| Network port protection: | 2KV lightning protection |
| System protection: | watchdog, prevent crash |
| Size and weaght | 390mm*130mm*44mm, net weight 3.5kg |
| Model: | DIU-8ETH |
Characteristics :
